Öljytön ruuvikompressori

Vesi-injected oil-free screw Kompressorit for applications requiring 100% oil-free compressed air. Available with fixed speed and VSD. Low-energy models with 3.0 bar for specific processes.

2.2 – 500 kWTeho

2.5 – 10.0 barPaine

0.21 – 86.01 m³/minVapaa ilmansyöttö (FAD)

Mikä on öljytön kompressori?

An oil-free screw compressor produces 100% oil-free compressed air (Class 0) through water-injected compression — completely without risk of oil contamination in the air. This is an absolute requirement in industries such as food and beverage, pharmaceuticals, electronics manufacturing, and the chemical industry, where even minimal traces of oil can destroy products or compromise patient safety.

Instead of oil, the compressor uses water to cool and seal during the compression process. This delivers clean compressed air directly from the compressor without the need for expensive aftertreatment systems for oil separation. Models are available with both fixed speed and VSD (variable speed) for optimal energy efficiency, as well as low-pressure versions (3.0 bar) for specific process applications.

With a power range from 2.2 kW to 500 kW and capacities up to 86 m³/min, there are solutions for everything from smaller laboratories and bakeries to large-scale production facilities in the food, pharmaceutical, and semiconductor industries.

Oletko kiinnostunut?

Autamme sinua löytämään oikean ratkaisun yrityksellesi.

Lataa tuotetiedote

Tuoteluettelo

Lataa luettelo (PDF)

Avainominaisuudet

100% oil-free compressed air (Class 0)

Vesi-injected compression

Available in fixed speed and VSD

Low-pressure models (3.0 bar) available

Ideal for food, pharmaceutical, electronics, and chemical industries

Mallit ja tekniset tiedot

Malli	Art.nr	Teho	Paine	Vapaa ilmansyöttö (FAD)	Melu	Paino	Mitat	Jäähdytys	Suojausluokka (IP)
DWW-44	30-16000-A	44 kW	7.0–10.0 bar	4.14–4.79 m³/min	80 dB(A)	1 620 kg	2000×1236×2165 mm	—	IP55
DWW-45	30-16000-A	45 kW	7.0–10.0 bar	5.10–7.70 m³/min	72–75 dB(A)	1 960 kg	2500×1600×2080 mm	—	IP55
DWW-55	30-16001-A	55 kW	7.0–10.0 bar	6.48–8.87 m³/min	75 dB(A)	1 960 kg	2500×1600×2080 mm	—	IP55
DWW-75	30-16002-A	75 kW	7.0–10.0 bar	10.43–12.60 m³/min	75–77 dB(A)	2 250 kg	2500×1600×2080 mm	—	IP55
DWW-90	30-16003-A	90 kW	7.0–10.0 bar	12.86–14.62 m³/min	77 dB(A)	2 315 kg	2500×1600×2080 mm	—	IP55
DWW-110	30-16004-A	110 kW	7.0–10.0 bar	15.41–17.50 m³/min	77 dB(A)	2 350 kg	2500×1600×2080 mm	—	IP55
DWW-132	30-16005-A	132 kW	7.0–10.0 bar	20.46–23.29 m³/min	77 dB(A)	2 675 kg	2800×1800×1860 mm	—	IP55
DWW-160	30-16006-A	160 kW	7.0–10.0 bar	26.23–27.28 m³/min	77 dB(A)	3 235 kg	2800×1800×1860 mm	—	IP55
DWW-200	30-16007-A	200 kW	7.0–10.0 bar	26.23–29.17 m³/min	77 dB(A)	3 345 kg	2800×1800×1860 mm	—	IP55
DWW75W	30-16002-W	73.6 kW	7.0–10.0 bar	11.10–12.12 m³/min	75 dB(A)	1 750 kg	2300×1600×1790 mm	Water	IP55
DWW90W	30-16003-W	88.3 kW	7.0–10.0 bar	13.00–13.13 m³/min	77 dB(A)	1 750 kg	2300×1600×1790 mm	Water	IP55
DWW110W	30-16004-W	110.3 kW	7.0–10.0 bar	16.00–19.50 m³/min	77 dB(A)	1 860 kg	2300×1600×1790 mm	Water	IP55
DWW132W	30-16005-W	128.7 kW	7.0–10.0 bar	19.44–23.00 m³/min	77 dB(A)	2 845 kg	2800×1800×1860 mm	Water	IP55
DWW160W	30-16006-W	158.1 kW	7.0–10.0 bar	23.00–26.30 m³/min	77 dB(A)	2 845 kg	2800×1800×1860 mm	Water	IP55
DWW185W	30-16007-W	183.9 kW	7.0–10.0 bar	26.23–29.17 m³/min	77 dB(A)	3 370 kg	2800×1800×1860 mm	Water	IP55
DWW200W	30-16008-W	198.6 kW	7.0–10.0 bar	29.05–35.00 m³/min	77 dB(A)	3 370 kg	2800×1800×1860 mm	Water	IP55
DWW220W	30-16009-W	220.7 kW	7.0–10.0 bar	32.39–37.63 m³/min	79 dB(A)	3 370 kg	2800×1800×1860 mm	Water	IP55
DWW250W	30-16010-W	257.4 kW	7.0–10.0 bar	37.32–45.20 m³/min	79 dB(A)	3 755 kg	2800×1800×1860 mm	Water	IP55
DWW280W	30-16011-W	275.8 kW	7.0–10.0 bar	41.56–45.50 m³/min	79 dB(A)	5 320 kg	3400×1900×2200 mm	Water	IP55
DWW315W	30-16012-W	312.6 kW	7.0–10.0 bar	45.37–50.09 m³/min	79 dB(A)	5 800 kg	3400×1900×2200 mm	Water	IP55
DWW355W	30-16013-W	349.4 kW	7.0–10.0 bar	49.98–56.96 m³/min	79 dB(A)	7 335 kg	3400×1900×2200 mm	Water	IP55
DWW400W	30-16014-W	393.5 kW	7.0–10.0 bar	56.65–67.36 m³/min	82 dB(A)	7 500 kg	4400×2200×2200 mm	Water	IP55
DWW450W	30-16015-W	441.3 kW	7.0–10.0 bar	67.10–78.07 m³/min	82 dB(A)	7 800 kg	4400×2200×2200 mm	Water	IP55
DWW500W	30-16016-W	492.8 kW	7.0–10.0 bar	77.82–86.01 m³/min	82 dB(A)	10 500 kg	5000×2200×2500 mm	Water	IP55

Sertifioinnit

CEISO 9001
